AMIDON T94-10 POWERED IRON TOROID

Anico
Model: T94-10
Availability: On stock
Not Rated
For EU private customers:
VAT is recalculated to your local VAT, when you add your country through checkout menu.
Companies with EU VAT number:
We deduct the VAT on the invoice, please put your EU VAT number to the Note column when you process the order through checkout menu!
For NON EU customers:
We charge the NET price (exl VAT). Shipping and insurance varies by countries. Please ask for quotation! Paying import duty and tax is your own task, insurance is your own risk.
2.52 EUR (2.12 EUR + VAT)
Qty:pieces

Description

Physical Dimensions



OD = .942 in / 23.9 mm +/- 0.02 in
ID = .560 in / 14.2 mm +/- 0.02 in
Ht = .312 in / 7.92 mm +/- 0.025 in
 AL=5.8 +/- 5 %      uH=(AL*Turns2)/1000
Temperature Stability (ppm /°C) = 150
Color Code = Black / Clear
Optimum Resonant Circuit Range
for highest Q and lowest core loss
15 MHz - 100 MHz
